The E6NN3K514EA hydraulic gear pump is a highly durable and efficient hydraulic component, specially designed for Ford tractors, including models 3500, 3600, 4100, 4500, 4600, 5100, 5600, 6600, 7100, and 7600. This tractor hydraulic pump is responsible for generating the hydraulic power required to operate various tractor functions, such as power steering, lifting arms and other auxiliary hydraulic systems. It is precisely engineered and features a gear-type mechanism, ensuring reliable and consistent fluid flow under high pressure.
This tractor hydraulic gear pump is made of high-quality materials and can withstand harsh agricultural and industrial environments, providing outstanding performance and a long service life. It is designed as a direct replacement for original components, ensuring seamless compatibility and easy installation. This kind of hydraulic gear pump is crucial for maintaining the operational efficiency and productivity of tractors.
E6NN3K514EA Hydraulic Gear Pump Specifications
| Applied to: | Ford Tractor 5110, 5610, 5900, 6410, 6610, 7010, 7610, 8010 |
| OEM Ref.No.: | E6NN3K514EA, E6NN3K514BA, E6NN3K514GA, 83958544, 87759440 |
| Nominal Displacement: | 11.0ml/r |
| Maximum Pressure· | 90bar |
| Rotational Speed: | 3000r/min |
| Controlled Flow Rate: | 16.0L/min |
| Fuel Feed Hole: | 5/8-18UNF |
| Fuel Discharge Hole: |
9/16-18UNF |
| Direction of Rotation: |
Left (Anti-clockwise) |
Tractor Hydraulic Gear Pump Components
- Pump Housing
The pump housing is the outer structure that encases the internal components of the hydraulic gear pump. It is typically made of durable materials like cast iron or aluminum to withstand high pressures, prevent fluid leakage, and provide structural stability during operation. - Drive Gear
The drive gear is a critical rotating component that transmits mechanical energy from the tractor's engine to the hydraulic pump. This gear works with the driven gear to create suction, drawing hydraulic fluid into the tractor hydraulic pump and generating consistent pressure for the system. - Driven Gear
The driven gear is paired with the drive gear and rotates in synchronization inside the pump housing. Together, these gears trap and transfer hydraulic fluid, ensuring a steady flow of pressurized fluid to power the tractor's hydraulic systems. - Inlet and Outlet Ports
The tractor hydraulic gear pump features inlet and outlet ports for fluid movement. The inlet port allows hydraulic fluid to enter the pump, while the outlet port directs pressurized fluid to various tractor systems, such as lift arms, steering, or auxiliary equipment. - Shaft and Bearings
The pump's shaft connects the drive gear to the tractor's engine or power source. Bearings support the shaft, ensuring smooth rotation and minimizing friction. These components are essential for maintaining the pump's efficiency and reducing wear over time. - Sealing Mechanisms
Sealing mechanisms, such as O-rings and gaskets, are used to prevent hydraulic fluid leakage from the hydraulic pump for tractor. These seals are critical for maintaining pressure within the system, ensuring efficient operation, and preventing contamination of the hydraulic fluid.
Tractor Hydraulic Gear Pump Applications
- Power Steering Systems
Hydraulic gear pumps are essential for supplying pressurized fluid to tractor power steering systems. This ensures smooth and responsive steering, allowing operators to maneuver heavy tractors easily, even under challenging field conditions or while towing large equipment. - Hydraulic Lift Arms
The tractor hydraulic pump powers the hydraulic lift arms, enabling operators to raise, lower, and control attachments like plows, mowers, and loaders. This application is crucial for efficient handling of agricultural implements and materials during farming or construction tasks. - Auxiliary Hydraulic Implements
Tractor hydraulic gear pumps provide the necessary pressure for operating auxiliary implements such as backhoes, log splitters, and post-hole diggers. These tools rely on consistent hydraulic power for smooth, reliable, and precise operation in specialized applications. - Transmission and PTO Systems
Some hydraulic systems use tractor hydraulic pump gear pumps to power the tractor's transmission and power take-off (PTO) systems. This ensures proper functionality when transferring engine power to attachments like balers, sprayers, or other equipment that require dynamic torque. - Brake Systems
Hydraulic gear pumps support tractor braking systems by providing pressurized fluid for responsive and effective braking. This is particularly important for ensuring safety when operating tractors on slopes, carrying heavy loads, or in emergency situations. - Front-End Loaders
The hydraulic pump powers front-end loader systems, enabling the lifting, tilting, and dumping of buckets. This application is vital for handling materials such as soil, gravel, or crops, making the tractor highly versatile for both agricultural and industrial tasks.
