36*89/32*106 Agricultural Machinery Tractor Pto Shaft Parts Wide Angle clutch

Introducing the 36*89/32*106 Agricultural Machinery Tractor PTO Shaft Parts Wide Angle clutch. This brand new product comes with a 1-year warranty, perfect for a variety of industries including retail, energy & mining, food & beverage shops, and much more. Weighing 10 KG, this yoke type PTO drive shaft is an ordinary product with a wide angle joint, available in a yellow sprayed finish.

Specifications of WA Wide Angle Joint

Product Features

The 36*89/32*106 Agricultural Machinery Tractor Pto Shaft Wide Angle clutch is an exceptional product for the following reasons:

1. It features a cross kit of 36*89/32*106.
2. It holds the ISO & CE certification, guaranteeing its quality and safety.
3. It includes 1 3/8'' Z6 teeth.
4. Its yoke is processed by forging, ensuring its durability.
5. It's made of 45C material, ensuring its strength and longevity.

With these features, our product serves as a perfect replacement for the corresponding parts that are damaged on WA Wide Angle Joint for PTO Shaft.

Applications of The Product

WA (Wide Angle) joints in tractor Trục PTO have numerous applications in the field of agriculture. They offer enhanced flexibility and smooth power transmission, making them suitable for various agricultural tasks and terrain conditions. Here are some common applications:

1. Mowing and Cutting: WA joints enable smooth power transmission and flexibility, allowing the implement to follow the ground contours and maintain a consistent cutting height.
2. Tillage and Seedbed Preparation: WA joints ensure efficient power transfer even when the implement is working at sharp angles or across uneven terrain.
3. Balers and Hay Equipment: WA joints enable smooth rotation and power transfer, allowing the equipment to operate effectively even when the tractor and implement are not perfectly aligned.
4. Sprayers and Spreaders: WA joints provide the necessary flexibility for efficient power transmission, enabling accurate and consistent application across the field.
5. Landscaping and Ground Maintenance: WA joints ensure smooth power transfer, allowing precise control and maneuverability in these applications.

Types of Tractor PTO shaft torque limiters

Tractor PTO shaft torque limiters are safety devices designed to protect the PTO system and connected equipment from excessive torque and prevent damage or accidents. Here are some common types of PTO shaft torque limiters used in tractors:

1. Shear Pin Torque Limiter: Uses a shear pin to transmit torque. When the torque exceeds a predetermined limit, the shear pin shears off, disconnecting the power transmission.
2. Friction Clutch Torque Limiter: Uses a disc or plate clutch mechanism to limit torque transmission. When the torque exceeds a certain threshold, the clutch slips, decoupling the power transmission temporarily.
3. Ball Detent Torque Limiter: Utilizes a ball mechanism to limit torque transmission. When the torque exceeds a specific limit, the balls are forced out of their detents, causing the clutch to slip and interrupting power transmission.
4. Ratchet Torque Limiter: Employs a ratchet mechanism to limit torque transmission. They consist of a series of teeth that engage and disengage under torque load.
5. Slip Clutch Torque Limiter: Utilizes a clutch mechanism with adjustable friction to limit torque transmission. The clutch slips when the torque exceeds a certain threshold, temporarily interrupting power transmission.

How Does the WA Wide Angle Joint for PTO Shaft Work?

The WA (Wide Angle) joint for a PTO (Power Take-Off) shaft works by providing flexibility and smooth power transmission at extreme operating angles. Here's how it works:

1. The construction of a WA joint consists of two yokes or flanges connected by a central cross or spider. Each yoke is attached to the respective end of the PTO shaft and is equipped with needle bearings.
2. When the tractor's engine is running, power is transferred through the PTO shaft to the WA joint. As the PTO shaft rotates, the WA joint flexes and adjusts its angle to match the alignment of the tractor and the implement.
3. The design of the WA joint enables it to handle a wider range of operating angles compared to traditional universal joints.
4. The WA joint's ability to flex and rotate smoothly is essential in agricultural applications where the terrain may be uneven or when the implement needs to be operated at sharp angles.
5. The WA joint is usually used in the outer sections of the PTO shaft, closer to the implement end.

Maintenance and Lubrication of the Product

Proper maintenance and lubrication are essential to ensure the optimal performance and longevity of the WA (Wide Angle) joint in a tractor PTO (Power Take-Off) shaft. Here are some guidelines for maintaining and lubricating the WA joint:

1. 1. Regular Inspection: Periodically inspect the WA joint for any signs of wear, damage, or loose components.
   2. Cleaning: Before lubricating the WA joint, clean it thoroughly to remove dirt, debris, and old lubricant. Use a suitable solvent or degreaser to clean the joint surfaces and components.

1. 1. Lubrication: Apply a high-quality grease specifically designed for universal joints to lubricate the WA joint.
   2. Seal Inspection: Check the seals around the WA joint for any signs of damage or deterioration.
   3. Regular Re-greasing: Establish a regular maintenance schedule for re-greasing the WA joint.
   4. Protecting Against Environmental Factors: When operating in harsh or corrosive environments, take additional measures to protect the WA joint.

Why Choose AGKNX's WA Wide Angle Joint for PTO Shaft?

AGKNX Drive Shaft Co., Ltd., located in Hangzhou Zhejiang City, specializes in developing, manufacturing, and marketing PTO shafts, hộp số nông nghiệp, industrial cardan shafts, and much more. Our products gained a great reputation from European, American, Asia, Australian, and North American customers. We are the top professional OEM supplier for many agricultural implement factories in the domestic market.

AGKNX Driveshaft insisted on our principles: Quality first, Deliver quickly, and Price Competitive. We already have the CE, TS/16949, and ISO9001 certificates with systematic manufacturing types of equipment and a QC team to guarantee our quality and delivery.

Currently, our company exports its products to its valued customers in more than 50 countries in 5 continents of the world. Having the best-in-class brands in its product range, AGKNX continues its activities with the aim of becoming a global company in the fields it works.

With our high level of professionalism, international certifications, customized services, advanced production facilities, and excellent after-sales services, AGKNX is your top choice for high-quality PTO shaft accessories.
