PTO Shaft T3 Crossφ27*70; 1-3/8″ 6 Spline;Triangle Pipe 80mm black for Tractor

Manufactured by China AGKNX Group, the PTO Shaft T3 is a versatile and robust addition to the range of tractor components. The unit is power-rated at 540RPM for 30HP with an overall closed length of 800mm. The universal joint size is 27mm x 70mm with both the tractor and implement ends being 1-3/8″ x 6 Spline. The shaft is constructed from 20CrMnTi / Q345 steel with forging used for the yoke material. The tube type can be triangular, star, square, hexangular, spline, or special on demand. The unit weighs 8Kg and is available in green, orange, yellow, or black.

The Structure of PTO Shaft:

PTO Shaft Parts:

PTO Shaft Tube:

PTO Shaft Cross Joint:

Key Features of the PTO Shaft T3

The PTO Shaft T3 offers a host of features that make it an ideal replacement part for damaged Agricultural PTO 샤프트. These include:

1. 1. Robust Construction: The shaft is made from high-quality 20CrMnTi / Q345 steel, ensuring long-term durability and robustness.
   2. Versatile Tube Type: The tube type can be customized to be triangular, star, square, hexangular, spline, or special based on specific needs.
   3. Powerful Performance: With a power rating of 30HP at 540RPM, it provides reliable and consistent operation.
   4. Universal Fit: The 1-3/8″ x 6 Spline ends, make it compatible with various tractors and farming implements.
   5. Color Options: Available in green, orange, yellow, or black, it can match your farming equipment's color scheme.

As manufacturers, we have the capability to produce this high-quality product, making it a perfect replacement for corresponding parts in Agricultural PTO Shafts.

Applications of the PTO Shaft T3

The PTO Shaft T3 can be used in a wide range of applications, including:

1. Farm Tractors: The shaft can be used in various types of tractors, providing reliable power transmission.
2. Farming Implements: It is compatible with a wide range of farming implements such as mowers, toppers, and rotovators.
3. Power Equipment: The shaft can also be used in other types of power equipment where reliable power transmission is required.
4. Manufacturing Industry: In the manufacturing sector, the shaft can be used in machines and equipment that require power transmission.
5. Agricultural Industry: The PTO Shaft T3 is also ideal for use in the agricultural industry, being able to power a variety of machinery and equipment.

How Does the Agricultural PTO Shaft Work?

The agricultural power take-off (PTO) shaft is a critical component in connecting the tractor's power to various equipment such as mowers, balers, tillers, and more. Its working can be described in the following steps:

1. Power Source: The PTO shaft is connected to the rear of a tractor or other power source equipped with a PTO. The PTO is a rotating driveshaft that extends from the rear of the tractor's engine.
2. PTO Shaft: The PTO shaft is a telescopic, splined shaft that connects to the PTO output on the power source. It consists of two or more sections that can slide in and out to adjust the length. The shaft is usually made of steel and has a specific number of splines that match those on the PTO output.
3. Implement Connection: The other end of the PTO shaft is connected to the input of the agricultural implement. The implement typically has a PTO input shaft that matches the splines on the PTO shaft.
4. Splined Coupling: To connect the PTO shaft to the implement, a splined coupling mechanism is used. It consists of two halves with matching splines. One half is attached to the PTO shaft, and the other half is attached to the implement's input shaft. When the two halves are aligned, they are engaged by sliding them together, creating a solid connection.
5. Power Transmission: Once the PTO shaft is connected, power is transmitted from the power source to the implement through the rotating PTO shaft. As the power source rotates the PTO shaft, the implement's input shaft also rotates, driving the machinery or implements attached to it. The PTO shaft transfers the rotational energy, enabling the implement to perform its intended function, such as cutting grass, tilling soil, or harvesting crops.
6. Operational Control: The operator can control the power transmission by engaging or disengaging the PTO. This helps in efficiently managing the operations of connected implements.

Installation of the PTO Shaft T3

The installation of the PTO Shaft T3 involves the following steps:

1. Safety Precautions: Before beginning the installation process, ensure that the power source is turned off, the engine is shut down, and the tractor is parked on a level surface. Use appropriate personal protective equipment, such as gloves and safety glasses, to protect yourself during the installation process.
2. Select the Correct PTO Shaft: Ensure that you have the right PTO shaft for your equipment and tractor. Consider the required length, spline size, and RPM rating of the PTO shaft to match your specific needs.
3. Adjust Shaft Length: If your PTO shaft is telescopic, adjust the length to match the distance between the power source's PTO output and the implement's PTO input. Avoid extending the shaft to its maximum length, as it may reduce stability and increase the risk of damage.
4. Attach the PTO Shaft to the Power Source: Connect one end of the PTO shaft to the power source's PTO output. Align the splines on the PTO shaft with those on the PTO output and slide the shaft onto the output until it fits securely. Ensure that the locking mechanism, such as a collar or pin, engages to prevent the shaft from disconnecting during operation.
5. Connect the PTO Shaft to the Implement: Align the splined coupling on the other end of the PTO shaft with the implement's PTO input shaft. Slide the two halves of the splined coupling together until they are fully engaged. Ensure that the coupling locks securely and that there is no excessive play or movement.
6. Secure the PTO Shaft: Use any provided locking mechanisms, such as retaining pins or collars, to secure the PTO shaft connections on both ends. These mechanisms prevent accidental disconnection of the shaft during operation.
7. Install Protective Shields: Ensure that the PTO shaft is adequately protected by installing the appropriate shields or guards. These shields should cover all rotating sections of the PTO shaft and prevent accidental contact. Secure the shields in place using the provided fasteners.
8. Test the PTO Shaft: Once the installation is complete, start the power source and engage the PTO. Observe the PTO shaft and connections to ensure smooth and balanced operation. Listen for any unusual noises or vibrations that may indicate misalignment or other issues. If any problems are detected, immediately turn off the power source and address the concerns before proceeding.

Maintenance and Care of the PTO Shaft T3

Proper maintenance and regular care of agricultural power take-off (PTO) shafts are crucial for ensuring their safe and efficient operation. Here are some maintenance tips to keep your PTO shaft in good condition:

1. Regular Inspections: Perform visual inspections of the PTO shaft before each use. Check for signs of wear, damage, or loose connections. Look for any cracks, bends, or missing parts. Inspect the protective shields or guards for any signs of damage or wear as well.
2. Lubrication: Apply lubrication to the PTO shaft according to the manufacturer's recommendations. Lubricate the splines, sliding sections, and any moving parts. Proper lubrication reduces friction, prevents corrosion, and ensures smooth operation. Use a suitable lubricant recommended by the manufacturer.
3. Shield Maintenance: Check the condition of the protective shields or guards regularly. Ensure that they are securely fastened and not damaged. Replace any shields that are cracked, broken, or missing. These shields are essential for preventing accidental contact with the rotating shaft, reducing the risk of injury.
4. Tighten Loose Connections: Over time, connections on the PTO shaft may become loose due to vibrations and normal usage. Check all bolts, pins, and fasteners and tighten them as necessary. Be careful not to overtighten, as it can cause damage or deformation.
5. Balance and Alignment: Imbalanced or misaligned PTO shafts can cause excessive vibrations, leading to premature wear and potential failure. If you notice vibrations during operation, have the shaft inspected for balance and alignment issues.
6. Replace Worn or Damaged Parts: If you identify any worn or damaged components during inspections, replace them promptly. This includes worn-out splines, damaged couplings, or any other parts that affect the performance or safety of the PTO shaft.
7. Safe Storage: When not in use, store the PTO shaft in a clean, dry area away from moisture, chemicals, and direct sunlight. Protect it from any potential physical damage or contact with sharp objects. Proper storage helps prevent corrosion and extends the lifespan of the shaft.

Why Choose AGKNX's Agricultural PTO Shafts?

AGKNX HZPT Drive Shaft Co., Ltd., located in Hangzhou Zhejiang City, is a leading manufacturer of PTO Shafts, 농업용 기어박스, Industrial Cardan Shafts, Car Driveshafts, U-Joint Coupling Shafts, Torque Limiters, PTO Shaft Tubes, and Universal Joints. Our commitment to quality, quick delivery, and competitive pricing has earned us a great reputation among our customers across the globe. We hold the CE, TS/16949, and ISO9001 certifications, and have a systematic manufacturing equipment and a dedicated QC team to ensure our quality and delivery.

We pride ourselves on our professionalism, international certifications, customized services, state-of-the-art production facilities, and comprehensive after-sales services. Our products are exported to more than 50 countries across five continents, and we aim to become a global leader in the fields we operate in.

Our team of experts is equipped with the knowledge and skills to provide you with the best agricultural parts that meet your needs. We prioritize customer satisfaction and are always ready to assist you with any queries you may have about our products. Trust us for reliable, high-quality, and efficient agricultural parts that will ensure the smooth running of your agricultural activities.
