47424536 Support Bar Fits for Case IH Combine Harvester

Product Specifications

Note: Our products are replacement parts and not original equipment. We provide perfect replacement products for original equipment. If you need to purchase the original equipment, please contact the original supplier.

Overview of 47424536 Support Bar Fits for Case IH Combine Harvester

The 47424536 Support Bar is a high-quality replacement part manufactured by AGKNX Group. Designed to fit Case-IH Combine models AF4077 and AF4088, this support bar offers exceptional durability and performance for agricultural applications. It is an essential component for ensuring the smooth operation and efficient harvesting of crops.

The support bar is constructed with precision and attention to detail. Its natural color or oiling finishing provides added protection against rust and corrosion, ensuring a long lifespan in demanding farming conditions. With a weight of 4.7KG, it offers a sturdy and reliable support system.

When it comes to packaging, you have the option of carton packing or wooden box packing. This allows for convenient transportation and storage, ensuring that the support bar arrives in perfect condition.

With its compatibility with Case-IH Combine models AF4077 and AF4088, the 47424536 Support Bar is a reliable and essential accessory for efficient harvesting. Count on its exceptional strength and durability to enhance the performance of your combine harvester.

Function and Use of 47424536 Support Bar Fits for Case IH Combine Harvester

The 47424536 Support Bar is an important component for Case IH combine harvesters. It serves the primary function of providing support to the combine harvester's threshing and separation system.

As the combine harvester moves through the field, the 47424536 Support Bar keeps the threshing and separation system stable, preventing any vibrations or wobbling of the system that could lead to grain loss or damage. It also helps to improve the efficiency of the threshing and separation process, ensuring that the grain is separated from the straw effectively.

The 47424536 Support Bar works by connecting the threshing and separation system to the main frame of the combine harvester. It is designed to withstand the rigors of the harvesting process, including the weight of the grain and the impact of bumps and uneven terrain.

Without the 47424536 Support Bar, the threshing and separation system would be prone to instability, which could result in grain loss or damage. It could also lead to decreased harvesting efficiency, as the combine harvester would need to slow down to compensate for the instability.

In conclusion, the 47424536 Support Bar is a crucial component for Case IH combine harvesters. Its primary function is to provide stability and support to the threshing and separation system, ensuring efficient harvesting and preventing grain loss or damage.

Advantages of 47424536 Support Bar Fits for Case IH Combine Harvester

The 47424536 Support Bar is an essential component for the Case IH Combine Harvester, and it offers several advantages that make it an indispensable part of the machine. Here are some benefits of using this support bar in the agricultural combine harvester:

1. Improved Harvester Stability: The 47424536 Support Bar provides stability to the harvester by ensuring that the header stays level during the harvesting process. This stability prevents losses due to crop spillage and enhances the overall efficiency of the harvester.

2. Increased Crop Yield: By providing stability to the header, the 47424536 Support Bar ensures that the harvester can cut the crops cleanly and efficiently. This feature prevents crop damage and increases the yield of the machine.

3. Longer Operational Life: The 47424536 Support Bar is made from high-quality materials that can withstand the rigors of the harvesting process. This durability ensures that the bar lasts for a long time and reduces the need for frequent replacements.

4. Enhanced Safety: The 47424536 Support Bar ensures that the header stays level and prevents crop spillage, which can be dangerous for the operator. This feature reduces the risk of accidents and enhances the safety of the operator.

5. Easy Installation: The 47424536 Support Bar is easy to install, and it can be done without the need for specialized tools or equipment. This feature reduces downtime and increases the productivity of the harvester.

6. Cost-Effective: The 47424536 Support Bar is an affordable component that offers several benefits to the harvester. This feature ensures that the harvester remains cost-effective and provides a good return on investment.

Overall, the 47424536 Support Bar is an indispensable component for the Case IH Combine Harvester. Its stability, durability, and safety features make it an important part of the machine, which enhances efficiency and improves crop yield.

How to Replace a Damaged 47424536 Support Bar Fits for Case IH Combine Harvester

Replacing a damaged 47424536 support bar in a Case IH Combine Harvester is an intricate process that requires careful attention to detail. Here are the steps involved:

1. First, you need to make sure that the harvester is turned off and the engine is cool. Safety should always be your top priority when working with machinery.
2. Next, locate the damaged support bar. In most cases, it will be easily visible and accessible but if it's not, you may need to remove other parts to get to it.
3. Use a wrench to remove the bolts securing the damaged support bar in place. You may need to use penetrating oil to help loosen any rusted bolts.
4. Once the bolts are removed, gently lift out the damaged support bar and set it aside.
5. Take your replacement 47424536 support bar and insert it into the same location where the old one was removed. Make sure it's properly aligned and secure before moving to the next step.
6. Reinsert the bolts and tighten them to the recommended torque. Always refer to the manufacturer's instructions to ensure that you're using the correct torque settings.
7. Double-check that all bolts are tightened securely and that the new support bar is properly aligned.
8. Lastly, start the harvester and run it for a few minutes to make sure that everything is working properly. Check for any leaks or abnormal sounds.

By following these steps, you should be able to replace a damaged 47424536 support bar in your Case IH Combine Harvester. Always remember to prioritize safety and refer to the manufacturer's instructions for specific details.

Other Replacement Combine Harvester Parts for Case IH and New Holland

1. Idler Pulley:

The idler pulley is a critical component in the belt drive system of combine harvesters. It helps maintain proper tension and alignment of the belts, ensuring smooth power transmission to various parts of the machine. A worn or damaged idler pulley can lead to belt slippage, reduced efficiency, or machine downtime, making timely replacement essential for optimal performance.

2. Drive Pulley:

The drive pulley is responsible for transmitting power from the engine to other mechanical systems within the combine harvester. It works in tandem with the belts, ensuring that the machine's components operate efficiently. Over time, drive pulleys can wear down, causing reduced power transfer or belt misalignment, necessitating replacement to maintain smooth operation.

3. Gears:

Gears are essential for transferring power within the drivetrain and cutting systems of combine harvesters. They are precision-engineered to handle high loads and ensure synchronized operation of various moving parts. Damaged or worn gears can lead to inefficient power transmission, increased wear on other components, and reduced machine reliability, requiring prompt replacement.

4. Drive Shaft:

The drive shaft transmits rotational power from the engine to various parts of the combine harvester, such as the cutting platform or threshing mechanism. It is designed to handle heavy loads and continuous use. A failing drive shaft can cause vibrations, loss of power, or complete system failure, making it a key component that requires proper maintenance and replacement when needed.

5. Drive Hub:

The drive hub connects the drive shaft to other rotating components, such as the cutting blades or threshing drum. It ensures smooth and reliable power transfer while maintaining alignment. A damaged drive hub can lead to misalignment, excessive wear on connected parts, or uneven operation, necessitating its timely replacement.

6. Knife Blade:

Knife blades are crucial for cutting crops during harvesting. These sharp, durable components are mounted on the cutting platform and work in conjunction with knife guards. Over time, knife blades can dull or break due to contact with rocks or tough vegetation, requiring replacement to ensure clean, efficient cutting and prevent crop loss.

7. Drive Sprocket:

The drive sprocket is a key component in the chain-driven systems of combines. It transmits power to chains that drive various mechanisms, such as the feeder or threshing system. Worn sprocket teeth can result in chain slippage or breakage, reducing operational efficiency and requiring replacement to maintain functionality.

8. Idler Sprocket:

The idler sprocket maintains proper chain tension and alignment in chain-driven systems. It ensures that the drive chain operates smoothly without excessive slack or wear. A damaged or misaligned idler sprocket can lead to chain failure and downtime, making regular inspection and replacement critical for reliable operation of the combine harvester.
