G Type Split Taper Bushings
G Type Split Taper Bushings are precision-engineered components used to mount pulleys, sprockets, or couplings onto shafts in mechanical power transmission systems. Featuring a double-split barrel and a solid flange, they ensure superior concentricity and a secure grip on the shaft. The 3/4″ per foot taper provides self-locking mechanical strength, reducing slippage. Made from durable materials like sintered steel or ductile iron, they accommodate various bore sizes and include cap screws for easy installation and removal, enhancing versatility and maintenance efficiency.
G Type Split Taper Bushings are precision-engineered components used to mount pulleys, sprockets, or couplings onto shafts in mechanical power transmission systems. Featuring a double-split barrel and a solid flange, they ensure superior concentricity and a secure grip on the shaft. The 3/4" per foot taper provides self-locking mechanical strength, reducing slippage. Made from durable materials like sintered steel or ductile iron, they accommodate various bore sizes and include cap screws for easy installation and removal, enhancing versatility and maintenance efficiency.
G Split Taper Bushing Dimensions
 |  |
| Bushing Type: | G | |
| Dimensions(in): | L | 1 |
| U | 1/4 | |
| T | 3/4 | |
| D Large End | 1.172 | |
| D Small End | 1.133 | |
| H | 2 | |
| W | - | |
| X | 5/8 | |
| Y | 3/16 | |
| R | 1/8 | |
| Bolt Circle (V): | 1-9/16 | |
| Stock Bore Range(in): | Type1(Min.) | 3/8 |
| Type1(Max.) | 15/16 | |
| Type2(Min.) | - | |
| Type2(Max.) | 1 | |
| Cap Screws: | # of Screws | 2 |
| Thread Dia.(in) | 1/4 | |
| Length(in) | 5/8 | |
| Wrench Torque(in-lbs): | 95 | |
| Ave.weight(lbs): | 0.5 | |
Advantages of G Type Split Taper Bushings
G Type Split Taper Bushings offer several advantages for mounting pulleys, sprockets, and other components in mechanical systems. Here are the key benefits:
- Secure Shaft Connection: The double-split barrel design ensures a tight grip on the shaft, providing excellent concentricity. This minimizes slippage and maintains alignment, even under high torque, enhancing system reliability and performance.
- Easy Installation and Removal: The split taper design allows for quick mounting and dismounting without requiring extensive disassembly. This reduces downtime during maintenance, saving time and labor costs in industrial applications.
- Versatile Bore Size Compatibility: G Type bushings accommodate a range of bore sizes, both inch and metric, making them adaptable to various shaft diameters. This flexibility simplifies inventory management and application versatility.
- Enhanced Torque Transmission: The keyed connection to both shaft and hub, combined with the tapered fit, ensures positive drive and high torque transfer. This prevents component loosening, improving power transmission efficiency.
- Improved Concentricity: The solid flange and double-split barrel maintain precise alignment between the bushing and mounted component, reducing vibration and wear. This enhances machinery longevity and operational smoothness in demanding conditions.
- Durability Under Load: Constructed from high-grade steel, these bushings withstand heavy loads and harsh environments. Their robust design ensures long-lasting performance, reducing the need for frequent replacements and maintenance costs.
- Interchangeability Across Brands: G Type bushings are standardized, allowing compatibility with components from different manufacturers. This interchangeability simplifies sourcing and replacement, providing flexibility in design and repair without proprietary constraints.
Applications of G Type Split Taper Bushings
G Type Split Taper Bushings are versatile components used in various mechanical applications. Here are their key applications:
- Mounting Pulleys for Power Transmission: G Type Split Taper Bushings securely mount pulleys onto shafts in belt-driven systems, ensuring reliable torque transfer. Their tapered design and split construction provide a tight grip, reducing slippage and enhancing efficiency in machinery like conveyors and HVAC systems.
- Sprocket Installation in Chain Drives: These bushings are used to attach sprockets to shafts in chain drive systems, offering easy installation and removal. Their double-split barrel ensures concentricity, minimizing wear and maintaining alignment in applications like industrial conveyors and agricultural equipment.
- Coupling Attachment for Shaft Alignment: G Type bushings facilitate the connection of couplings to shafts, ensuring precise alignment and torque transmission. Their self-locking taper design prevents loosening, making them ideal for heavy-duty applications such as pumps and compressors.
- Sheave Mounting in Belt Systems: They are employed to mount sheaves in V-belt or flat-belt systems, providing a secure fit. The bushings’ flange and keyway design enhance holding power, supporting high-speed operations in machinery like milling equipment and lathes.
- Gear Attachment in Gearboxes: These bushings are used to fix gears to shafts in gearboxes, enabling smooth power transfer. Their robust steel construction and tapered fit ensure durability and precision in demanding environments, such as automotive and manufacturing systems.
- Adjustable Component Positioning: G Type bushings allow for easy repositioning of components like pulleys or sprockets on shafts. Their split design simplifies maintenance, reducing downtime in industries such as packaging and material handling where frequent adjustments are needed.
 |  |
